| Brand Name : | Liocrebif |
| Model Number : | LKF-OE25M/05M |
| Certification : | GJB 9001C-2017 |
| Price : | 5000-25000CHY |
| Payment Terms : | T/T |
| Supply Ability : | 10000 |
| Delivery Time : | 2-4 weeks |
Main Performance
Number of Contact Pins | 2~7 cores |
Contact Resistance | <20 mQ |
Insulation Resistance | >2000MΩ (normal), >1000MΩ (environmental testing) |
Dielectric Voltage | ≤1500V DC, 1 min |
Single-Core Current Rating | ≤20A |
Insertion Loss | 1.2dB standard / 0.6dB low loss (1310nm) |
1.0dB standard / 0.5dB low loss (1550nm) | |
Mechanical Life | >500 cycles |
Factory Test Pressure | Standard lateral 5MPa, customizable up to 20MPa lateral pressure, customizable receptacle with longitudinal waterproofing |
Operating Temperature | -45°C to 90°C |
Connector housing | Standard stainless steel 316L, customizable titanium alloy TC4; |
Optical contact | Zirconia ceramic pins |
Electrical contact | Gold-plated brass |
Sealing end cap | Stainless steel 316L |
Cable | Polyurethane cable or rubber-sheathed cable |
Connector Arrangement
Number of cores: 2 optical/electrical Single-core current rating: 20A Operating voltage: 1000V DC/AC rms Dielectric voltage: 1500V DC Insertion loss: ≤1.0dB@1550nm |
Number of cores: 4 optical/electrical Single-core current rating: 10A Operating voltage: 500V DC/AC rms Dielectric voltage: 1500V DC Insertion loss: ≤1.0dB@1550nm |
Number of cores: 7 optical/electrical Single-core current rating: 5A Operating voltage: 500V DC/AC rms Dielectric voltage: 1000V DC Insertion loss: ≤1.0dB@1550nm |
Note: Customization is available to support optical, electrical, and RF transmission requirements with different core counts. | ||
Dimensions Of The External Structure
Plug shape
OE25M/05MTEXFY Vertical Tail Attachment Configuration
Outlet shape
OE25M/05MI Outlet
OE25M/05MF Outlet
Sealing Cap Profile
|
|
